3D碳钢和不锈钢线材数控折弯机自动金属线材折弯机3D
工厂介绍
邢台中德机械制造有限公司专业生产各种类型的机械。我们拥有十多年的机械设计和生产经验，坚持自主研发，并拥有机械研发专利。我们目前的产品包括对接焊接的线材弯曲机、3D线材弯曲机和2D线材弯曲机，我们可以根据客户的要求进行生产。这些产品已出口到美国、德国、巴基斯坦和澳大利亚。我们有20名机器设计师和工程师，他们可以定制机器以满足客户的要求。我厂位于河北省邢台市机械之乡，占地30000平方米。我们有100多套设备，由300名工人操作。我们还拥有一支高素质的技术团队，致力于开发新产品和处理客户定制订单。我们的年出口额超过900万美元。在过去的20年里，我们开发了500多种机械，并以我们的品牌销售所有系列。本着“诚信、质量、服务”的原则，我们已经获得了ISO认证，同时，所有产品都符合CE标准的要求，质量好，我们的产品在所有客户中享有很高的声誉，与许多著名的机械进口商有过合作。我公司承诺：价格合理，生产时间短，售后服务满意。我们有信心生产最好的机器和服务，如果您对我们的任何机器感兴趣，请随时与我们联系。我们很荣幸有机会与贵公司建立业务关系。
我们的优势
CNC system 8 axes 3D wire bending machine manufacturer wire forming machine 3-8 mm
FAQ
1. What is the voltage/phase for this 3D CNC wire bending machine ?
220V 50Hz/single phase, 380V 50Hz/three phase, also can made as the clients’ need.
3. Do you have the products in stock?
Yes , We have some model products can supply to you.
4. Can we use English or other languages on the display screen?
Yes, we can. The system can achieve many languages, such as English, French, Russian, Spanish, and other languages.
5. How to choose a model?
First you could check with parameters list, or advise the requirement directly, then we would help you to choose a model accordingly.
6. How about After-sales service?
We freely send technicians to your country and 24 hours on-line service.
7轴全自动高精度数控3D线材折弯机，线材车削式，适用于直径4-10mm的线材。机器采用先进品牌电机和优质材料——不锈钢、CR12MOV和DC53，坚固稳定。7轴三维弯线机采用数控控制系统。它是全自动的，易于操作。数控三维弯线机可以制作各种二维和三维形状。它广泛应用于我们的日常生活中，如自行车零件、汽车零件、厨房用具金属工具、购物车、五金、家具等。3D折弯机可以制作各种金属形状。
我们也可以根据客户的要求制造机器。客户可以选择日本电机或国产电机------先进电机。我们将为客户提供最好的服务和售后服务。
技术参数| 型号 | ZX-3D-4010 |
| 线径范围 | 4-10mm |
| 轴数 | 7轴 |
| 送线精度 | ±0.1mm |
| 送线电机功率 | 5.5KW |
| 转线电机功率 | 2.9KW |
| 折弯电机功率 | 2.4KW |
| 内外模旋转电机功率 | 1.8KW |
| 内外模升降电机功率 | 1.0KW |
| 平台升降电机功率 | 1.0KW |
| 切刀电机功率 | 1.3KW |
| 尺寸 | 3900*1200*1700mm |
| 机器重量 | 2000kg |
邢台中德机械制造有限公司专业生产各种类型的机械。我们拥有十多年的机械设计和生产经验，坚持自主研发，并拥有机械研发专利。我们目前的产品包括对接焊接的线材弯曲机、3D线材弯曲机和2D线材弯曲机，我们可以根据客户的要求进行生产。这些产品已出口到美国、德国、巴基斯坦和澳大利亚。我们有20名机器设计师和工程师，他们可以定制机器以满足客户的要求。我厂位于河北省邢台市机械之乡，占地30000平方米。我们有100多套设备，由300名工人操作。我们还拥有一支高素质的技术团队，致力于开发新产品和处理客户定制订单。我们的年出口额超过900万美元。在过去的20年里，我们开发了500多种机械，并以我们的品牌销售所有系列。本着“诚信、质量、服务”的原则，我们已经获得了ISO认证，同时，所有产品都符合CE标准的要求，质量好，我们的产品在所有客户中享有很高的声誉，与许多著名的机械进口商有过合作。我公司承诺：价格合理，生产时间短，售后服务满意。我们有信心生产最好的机器和服务，如果您对我们的任何机器感兴趣，请随时与我们联系。我们很荣幸有机会与贵公司建立业务关系。
我们的优势
CNC system 8 axes 3D wire bending machine manufacturer wire forming machine 3-8 mm
| Model | ZD-3D-308 |
| Diameter | 3-8 mm |
| Number of axis | 8 |
| Feeding speed | 100m/min |
| Total servo motor power | 16.5 kw |
| Feeding servo motor power | 4.4 kw |
| Rotary servo motor power | 2.9 kw |
| Bending servo motor power | 2.4 kw |
| Platform lifting servo motor power | 1.0 kw |
| Cutting servo motor power | 1.0 kw |
| Internal and external mold lifting servo motor power | 1.0 kw |
| Inner and outer mold rotation servo motor power | 1.8 kw |
| Machine Head translation servo motor power | 1.0 kw |
| Weight | 2000 kg |
| Dimension | 3900*1200*1700 mm |
Founded in 1998, Xingtai Zhongde Machinery Co.,ltd specialized in manufacturing all kinds of
machinery. Our products now include 2D 3D wire bending machine, 2d wire bending machine,
bucket handle machine, paint roller machine, thread rolling machine, CNC stirrup bending machine,
nail making machine, screw making machine and so on. At the same time, we can produce
according to our customers request. These products have been exported to the USA, Germany,
Pakistan and Australia. We have 20 machine designer, 50 engineers and 300 workers.
machinery. Our products now include 2D 3D wire bending machine, 2d wire bending machine,
bucket handle machine, paint roller machine, thread rolling machine, CNC stirrup bending machine,
nail making machine, screw making machine and so on. At the same time, we can produce
according to our customers request. These products have been exported to the USA, Germany,
Pakistan and Australia. We have 20 machine designer, 50 engineers and 300 workers.
Our factory located in Xingtai, Hebei province, in a district known as machinery hometown,
occupying an area of 30,000 square meters. We have more than 100 sets of equipments, which
are operated by 300 workers. We also have a highly qualified technical team engaged in
developing new items and dealing clients customized orders. Our annual export amount is over
USD9,000,000.
are operated by 300 workers. We also have a highly qualified technical team engaged in
developing new items and dealing clients customized orders. Our annual export amount is over
USD9,000,000.
FAQ
1. What is the voltage/phase for this 3D CNC wire bending machine ?
220V 50Hz/single phase, 380V 50Hz/three phase, also can made as the clients’ need.
2. Can you make the logo or company name on the products or package?
Sure. customer's logo or company name can be printed on products by stamping, printing, embossing, coating or sticker.
Sure. customer's logo or company name can be printed on products by stamping, printing, embossing, coating or sticker.
3. Do you have the products in stock?
Yes , We have some model products can supply to you.
4. Can we use English or other languages on the display screen?
Yes, we can. The system can achieve many languages, such as English, French, Russian, Spanish, and other languages.
5. How to choose a model?
First you could check with parameters list, or advise the requirement directly, then we would help you to choose a model accordingly.
6. How about After-sales service?
We freely send technicians to your country and 24 hours on-line service.
